Arctic Leopard E · AT 560 TRIAL Bike

Model
E · AT 560 TRIAL

Frame
Cr-Mo steel frame

Length
2010mm

Width
825mm

Height
1100mm

Wheelbase
1320mm

Seat height
698mm

Ground clearance
310mm

Vehicle weight
65kg

Front wheel specification
2.75-21 (1.6-21 Yousheng 7 series ring)

Rear wheel specification
4.0-18 (2.15-18 Yousheng 7 series ring)

Front brake caliper
185mm/4 piston calipers

Special rear brake
185mm/2 piston calipers

Handlebar
22-28 reducer 6061

Tire (Mages)
Zhengxin

Front shock absorption as standard
40mm Fork Stroke 170mm

Standard rear suspension
Stroke 180mm

Special rear suspension
+180USD

Rear shock absorption of gas cylinder
+350USD

Maximum Range
80km

Maximum Speed
90km/h

Drive Ratio
520 11:39

Torque on wheel
560Nm

Maximum power
10kw

Motor efficiency
0.96

Power mode
Competition, sports, standards

Electronic brake
Yes

energy recovery
Yes

Reverse
Yes

Battery
72V 25Ah

Charge Time
600W（3h full）
